Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 418

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 418
f a house the eaves are usuallycarried from 6 to 24 beyond the house line, and the methodby which this projection is effected and the manner in whichit is deco atively treated must be thoroughly understood bythe draftsman when preparing general elevations. Exer-cise II, consisting of four sheets,… … DaU 5D-I LT 53D § 7 Time consumed inexecuting this sheet Aame of Student, Class Lettersand Number §7 ARCHITECTURAL DRAWING 19 19. Exercise II, Sheet I.—After drawing- the usual8 X 11 border line, locate the point a, Fig. 1, of Sheet I,6 below the top, and 3 to the right of the left border line.From…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
