Jig. 77.) on each side, serving more effectually to embrace thetimber. A f in. bolt {jj, in Jig. 77.) passes through the centreaf this casting, and vertically through the beam, to ^retainit in its place, until the tension bars are drawn up. Againstthis casting, in two semicylindrical seats, lie two…
