London : Longman, Rees, Orme, Brown, Green, and Longman · leaf 202
next drawn. In the engraving fig. 26., illustrative of these re-marks, a is the ground plan; 5, vertical plan ; c, plane equal-ising the rays; d, station point; e, ground line ; f, sky line ;and, when the diagram is turned round, g is the true perspectiveview of the object. Figs. 27. and 28. show… … Fig 23- shows that the door / h is represented by h o, a largerquantity; while the breadth is the same as by the scale. 33. Hill Street, Peckham, Oct. 183fi. 190 Candiduss Note-Book. Art. III. Candiduss Note-Booh. Fasciculus V. Sicut meus est mos,Nescio quid meditans nugarum; ct totus in illis. I.…
Architecture
