dows to light the nave. In Norman, Early English and Decorated churches of any importance we generally find the arcade, triforium and clerestory, but in the Perpendicular Period the triforium is more frequently entirely missing or has become a series of vertical panels as we saw in the nave.… … Plate V. 36 ARCHITECTURE Pilaster. The Early English designer found a wideprojecting mass of stone which he did not want, sohe placed two small crocketted gables on it and betweenthem started the delicate trefoil shaft to carry hisvaulting ribs. This illustration well shows the wonderfulchange of…
Drawing
