I■%, V &i Diameters … PLATE IX. 366 PLATE IX. Fig. 1. and 2. Exhibit the parts of a Roof in sectionand elevation as described in Chapter II.Book IV. a a. Beams (Trabes). b b. Ridge piece (Columen). c. King post (Columna). d d d. Tye beam (Transtrum). e. Strut (Capreolus). f f. Rafters (Cantherii). g g g g. Purlines…
