vation as described in Chapter II.Book IV. a a. Beams (Trabes). b b. Ridge piece (Columen). c. King post (Columna). d d d. Tye beam (Transtrum). e. Strut (Capreolus). f f. Rafters (Cantherii). g g g g. Purlines (Templa). h h. Common Rafters (Asseres). The above letters refer to both Figures 1.… … 4 PLATE X. 368 PLATE X. Fig. 1. Is a plan of a Tuscan Temple. Chapter VII.Book IV. The side A shews it in antis, theside B shews it prostylos.C. is the larger, and DD. the smaller cells. Fig. 2. Represents the elevation of the preceding Fi-gure. The arrangement of the intercolumnia-tions is…
