Gilroy, Clinton G · New York, G. D. Baldwin · leaf 220
eedles, numbered attheir points which pass through the front board U^, against whichthe cylinder strikes, (see Fig. 94.) It will now be perceived, thatby working the strap or band T (see Fig. 95) in the manner JACQ.UARD MACHINE. 199 just stated, the cylinder I I will be turned round upon its… … 200 THE ART OF WEAVING. The wires Z Z are turned up at their lower ends, as representedin Figs. 94 and 96, and into the loops thus formed small rods orslips of wood V^ y are inserted, from side to side of the machine,one rod passing through each row of needles, and the ends of theserods at one side…
Weaving
