The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 204
t, showing the cylinder, pierced with holes, for carryinground the endless chain of pattern cards; Fig. 94 is an end view, orthat part which presents itself to the weaver when seated on hisloom ; and Fig. 95 is a vertical section, taken transversely throughthe machine, showing the back board or… … We would here remark, that in describing the drawings just al-luded to, the same letters of reference indicate similar parts in all ofthem. A A, Fig. 95, is the frame of the machine, connected bysuitable cross bars at BBBB; the two upright posts C C, one at 25 194 THE ART OF WEAVING. each end of…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
