Gilroy, Clinton G · New York, G. D. Baldwin · leaf 265
fro, in order to lay theyarn evenly upon the surfaces of the bobbins, by means of the leverk, being moved by the heart or excentric motion /, (see Figs. 116and 117) geared with the other end of the driving shaft. It will be observed, by the drawing, that a sirailar arrangementis represented upon… … The apparatus necessary to perform the second part of the im-provements, namely, the arranging, printing, or stamping, and reel-ing of the threads or yarns, intended to be woven into carpets orrugs, is shewn in longitudinal elevation at Fig. 119. Any number of bobbins containing the yarns, are…
Weaving
