Gilroy, Clinton G · New York, G. D. Baldwin · leaf 429
392 THE ART OP WEAVING.Fig. 183. … wheels q^ is keyed fast upon the tappet shaft r r, upon which thethe tappets or cams s s s^ are also mounted ; thus it will be seen,that as this tappet shaft r r, revolves, the tappets sss^ will succes-sively actuate the treadle levers 11^ and divide the warp threads byshedding the headles at…
Weaving
