Gilroy, Clinton G · New York, G. D. Baldwin · leaf 96
Fig. 6 is a ground plan, or rather a horizontal section of a com-mon loom, parts of which are cut away, for the purpose of showingin their proper forms other parts of the loom, warp, and cloth, asthey could not be otherwise represented. Fig; 7. … 76 THE ART OF WEAVING. Fig. 7, may be considered either as a profile elevation, or as aprofile section of the same loom. All the parts in Fig. 7, are represented as they appear to a personStanding at one side of the loom, and many parts, concealed or cutaway in Fig. 6, are seen very plainly in Fig.…
Weaving
