The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 144
s, through which the whipthreads are drawn, will then appear as passing through the headlesor standards on the leaf C, the beads being in front at v ; and theunder bead lams will be seen as if rising through their standardson the leaf D, crossing below the others towards the front at x.The marks on… … Here the upper bead lam shaft is marked 1, and its standard C;the under lam 2, and its standard D, as in Fig. 55. When the openshed is formed, the bead lams assume the position represented in Fig.56 at x, and v, that is, the bead lam x, on the shaft 2, crosses infront of a standard on the shaft C,…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
