The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 178
6 are the knots (see Fig. 77,) on the raising and sinking cords, and 7 are mails attached to them. 8 is a weight for recovering the ma-chine, and 9 are weights for balancing the mounting, (see Fig. 77,)10, 10, are boards pierced with holes for conducting the knot cords,one of which is seen at 10,… … w, a cord for c, c, are weights for balancing the conducting cords conducting the pressing knot cords ; y, for conducting the raising 168 THE ART OP WEAVING. knot cords, and z, weights for keeping the knot cords tight, (seeFig. 77.) a, Fig. 78, is a view of the trap board, and 6, of thepressing…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
