The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 194
and. This improve-ment consists in using a barrel or cylinder, on the surface of which,the figure or pattern to be produced in the cloth is arranged in re-lief, precisely in the same way as tunes are disposed on the barrelof the common organ, or on that of a musical box, by inserting wire THE ART… … Fig. 85 represents a front view of this loom, as it appears whenthe shed is formed. A is the barrel; B a spur wheel fastened to its 184 THE ART OF WEAVING. end by the screws C C: this wheel, by means of proper catchesand other machinery, to be hereinafter described, governs the rota-tion of the…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
