ration of the looi Voi II 290 LOOM, DOUBLE-STROKE. Fig. 2659, illustration of the movement winch operates the picker-staff.Figs. 2660 and 2661, shuttle. Fig. 2658, elevation of the loom on the side of the warp.Figs. 2662 and 2663, plan and section of the brake.Fig. 2664, plan of one of the… … threads of the warp. EE, harness for raising and lowering the threads of the warp for the passage oithe shuttle. F, breast-beam. G, cloth-beam. H, spur-wheel on the shaft of the cloth-beam. /, pinionworking into the wheel II. I, ratchet-wheel, which works with the pinion. J, bell-crank, moving…
