The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 419
cementedtogether by means of a solution of caoutchouc. At Fig. 190, a modification of the improvements, and the modeof applying the same to fancy looms, is shown. The drawing re 400 THE ART OF WEAVING. presents a partial sectional view of the figuring apparatus, attachedto an ordinary loom side. An… … Fig. 191.I i i The moveable tappets, or teeth a a a, are suitably arranged upontheir bars or rails, (as in the former instance,) to weak the patternor device required, and are alternately caused to raise or depress thetreadles d d, successively, by acting upon the rollers e e, with whichthey are…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
