Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 113
the right, being controlled by the valve Bwhich is automatic in its action. The lift of this valvemay be varied to meet different requirements, by the ad-justable threaded spindle. 86 A UDELS ANSWERS Ques. What are the pressure conditions in the mixing chamber? Ans. In operation, the pressure in… … Fig. 35.—The mixing chamber with its appendages. Illustrating, ingeneral, the arrangement of parts, the primary, and secondary or auxiliaryair passages; auxiliary valve, spring and adjustment; the spray nozzle withneedle valve and the throttle valve. The arrows indicate the direction ofthe entering…
Automobiles
