Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 132
tter size be determined? Ans. By the area of the valve opening on the engineand not by the cylinder displacement. CARBURETTERS 105 Ques. Why is this? Ans. The valve opening area is a true measure of theengine capacity, because a carburetter cannot dehvermore charge to a cyhnder than the area of the… … Fig. 47.—A few examples of carburetter design, showing courses followedby the fuel after leaving the nozzle, for different arrangements of parts andpassages. The heavy arrowed line leading from the nozzle X indicates thecourse taken by the mixture as influenced by the design. These diagrams areself…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
