Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 185
rmal position of the interrupterlever G, the lower end presses against the contact piece E, beingkept in that position by the horseshoe-shaped spring K, whichpasses right over the top of the stem and lies in the slots in thesides. The top of the coil is fitted with a terminal screw, to whichthe… … Figs. 69 and 70.—A low tension ignition system with an inductor magnetoof the oscillating type. The inductor E is rotated to and fro by means of 9link R, one end of which is attached to the inductor crank, and the other t -the igniter cam C. Two views are shown: immediately before and…
Automobiles
