Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 216
coil, these being designatedrespectively: C, C, C, C, and each consisting of a primary winding Pand a secondary winding S. The primary windings are all united in parallel at the top by awire W, and with the lower ends connecting respectively with thesegments of the timer T. The primary winding MP,… … Fig. 107.—The Splitdorf master vibrator coil. As shown in the illustration,the several unit coils are indicated by the figures 1, 2. 3 and 4. A fifth unitV at the left contains the master vibrator. The primary wires P connectwith the timer and the secondary wires with the plugs. BB shows the…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
