f opening and closing itis repeated with great rapidity so long as the switch W remainsclosed. The cycle of actions may be briefly stated as follows: 150 HAWKINS ELECTRICITY 1. A primary current flows and magnetizes the core; 2. The magnetized core attracts the vibrator which breaks theprimary… … y HV—v—vr 5L Fig. 145.—The Splitdorf master vibrator coil. As shown in the illustration the severalunit coils are indicated by the figures 1, 2, 3, and 4. A fifth unit V at the left containsthe master vibrator. The primary wires P connect with the timer and the secondarywires S with the plugs. B B…
