Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 218
ferent vibrators. With a distributer and singlecoil, the lag is the same for all the cylinders, hence theapplication of the word synchronous. Ques. Describe the synchronous circuits. Ans. Fig. io8 is a wiring diagram showing the two cir-cuits. The primary circuit includes the battery,… … I I dONOENSER I I CONTACT SCREW I BPiTTERY Fig. 108.—Diagram illustrating the principles of synchronous ignition.For clearness, the primary and secondary elements of both the coil and thedistributer are shown separated. When the primary rotor of the distributercompletes the primary circuit, current…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
