Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 308
d L. Ques. Intermediate speed? Ans. For the intermediate speed the gears are shiftedso that I will come into mesh with I, L, of course, being TRANSMISSIONS 281 moved out of mesh with L^ The drive now is through C,C, r, I, and out through the shaft T to the rear axle. Ques. Reverse? Ans. To reverse,… … P Fig. 16S—Diagrram of a three speed progressive transmission. Thegears C, I and L are fastened to the countershaft, while I and L, slide on thesquare portion of the main shaft T; R is an idler and is used for the reverse.The various speed changes are made by altering the position of the…
Automobiles
