id on alternately for lugs, areplaced between the waxed paper sheets in piles of 100 sheetseach. The condenser will therefore comprise five units of100 sheets to the unit. The specifications given are for acondenser of large proportions, but in the authors experi-ence, the average amateur builder… … Fig. 34.—Diagram of connections for the induction coil menter is a letter press and this implement gives but asmall fraction of the pressure used by the manufacturerof the standard condenser. The diagrams of connections is given in Fig. 34. Thedisposition of the connecting wires is not given in the…
