Fig. 206.—Diagram showing the relative drop intosmall carriage wheel and on.- Iwkc- its diameter. road rut between a THE RUNNING GEAR 31,) Ques. How is the dish usually balanced? Ans. By slightly inclining the axle spindle from itscenter line, as shown in fig. 207, thus bringing the lowestspoke to… … The cut shows a Fig. 207.—To illustrate the inclination of the wheels.Matheson car having the front wheels incHned three degrees to balance thedishing of the spokes and bring the lowest spoke into a vertical position. Thus it is that a wheel five feet in diameter will sink onlyone-half inch in a…
