Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 389
bear-ings, and 10, universal clutch shaft joints. OIL EVERY 1000 MILES: i, steering axles, 2, springs, 3, gearshifting rods, 4, clutch parts, 5, compensating case, 6, forward 362 A UDELS ANSWERS clutch ball bearings, 7, sprocket shaft ball bearings, 8, wheelball bearings, 9, magneto, 10, fan… … Fig. 269.—The Hill precision oiler. In operation, the center post A re-volves by means of the worm wheel B, and the worm on the driving shaft C,which receives its motion from some part of the machine, either through a beltor ratchet. When the center post A is revolved, the plunger D is raised…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
