raw Fig. 7 ])elow and at the right of the eye andremove the part marked X. 35. Draw Fig. 8 below and at the left of the eye and removethe part marked X. 3(3. Draw Fig. 9 below and at the left of the eye and removethe part marked X. 37. Draw Fig. 11 below and at the right of the eye andremove the… … Fio-. 14 represents Fisr. 7 drawn below and at the left of theeye with X removed. Fig. 15 represents the same in a vertical AUGSBURGS DRAWING. 113 position. Fio^. 16 represents the same in a horizontal position,and Fig. 17 in an oblique horizontal receding position. All of the figures, 6-13, may be…
