New York, N.Y. : U.S. Industrial Pub. Co. · leaf 1030
to Figs. 10, 14 and 15, 10 indicates a frame or spider, which is fast upon countershaft 9. The shaft and frame are supported, as shown, by the bearing 11. The spider 10 has a series of lugs 12, which are integral with and in the same circle with lugs 13 upon the fly-wheel 8. Through the lugs 12 and… … Packard Carriage with cushion flap turned up, showing compression relier rocker, carbureter, fuel regulation, electric switch push buttons, vertical rock shaft, hand lever regulating searchlight, vertical gear controlling lever and emergency brake treadle the motor and the driving wheels, which…
Automobiles
Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
