t to thereading on the piston stem should be added the volume ofthe auxiliary cylinder. Tank E is a check volume of 7 cu.in., used only for calibration purposes. When the tubingis renewed, fitting F is screwed into the tank, screw Gloosened, and vernier H adjusted to read exactly 7. Measuring… … Fig. 2—Diagram of ac-tual instrument illus-trated in the photo-graph 20S AUTOMOTIVE INDUSTRIESTHE A UTOMOBILE February J, 1921
