used to clamp the driven plate between thefabric surfaces riveted to the rear cover and floatingplate respectively. Four multiplying levers serve fordisengagement purposes, but take no thrust from thespring when the clutch is engaged. Lubrication of the clutch coupling shaft is accom-plished by oil… … Cross section through engine incloses the springs and multiplying levers. Thethrust collar acted upon by the clutch fork floats onthe rear extension of the back plate and is preventedfrom rotating by means of a link carried to the frame,a combined journal and thrust ball-bearing being pro-vided to…
