e crank-shaft. Each ring has three cams and rotates at one-sixthengine speed. The two-throw crankshaft has three parallel-sided rollerjournals and a double-thrust ball bearing at the propellerend. It has bronze counterbalance weights bolted to ex-tensions of the outer webs and is drilled for… … Jaguar engine performance curves The master ring or big-end is a split steel bearing shellof two dissimilar parts with side webs carrying the con-necting rod pins, the webs being extended in the line ofthe master rod to accommodate the second pin which ineffect makes the big-end and master red a…
