Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 140
To Carburetor Wire Gauze \ To Carburetor^ Settling Chamber Settling Chamber … Fig. 55.—Types of Strainers Interposed Between Vaporizer and GasolineTank to Prevent Water or Dirt Passing Into Carbureting Device. separator because the gasoline is forced to pass throughthree filtering screens before it reaches the carburetor.The gasoline enters the device shown at C through a…
Airplanes
