Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 301
which interlock with the coupling. The 302 Aviation Engines ring shown at F is called the Evertite and is a three-piece ring composed of three members as shown in thesectional view below the ring. The main part or innerring has a circumferential channel in which the two outerrings lock, the… … Fig. 125.—Leak-Proof and Other Compound Piston Rings. results in each joint being sealed by the solid portion ofthe other rings. The use of a number of light steel rings instead ofone wide ring in the groove is found on a number ofautomobile power plants, but as far as known, this con-struction is…
Airplanes
