Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 303
whjch interlock with the coupling. The 302 Aviation Engines ring shown at F is called the Evertite and is a three-piece ring composed of three members as shown in thesectional view below the ring. The main part or innerring has a circumferential channel in which the two outerrings lock, the… … Fig. 125.—Leak-Proof and Other Compound Piston Bings. results in each joint being sealed by the solid portion ofthe other rings. The use of a number of light steel rings instead ofone wide ring in the groove is found on a number ofautomobile power plants, but as far as known, this con-struction is…
Airplanes
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
