Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 343
Motor inFront Tractor Screw--*in Front … VAl— ± Motor in Rear Fig. 157.—Showing Two Methods of Placing Propeller on Gnome Rotary-Motor. may be carried in tanks placed lower than the motor insome installations. The diagram given at Figs. 157 and158 shows other mountings of Gnome engines and areself-explanatory. The simple mounting possible…
Airplanes
