\SmJf^0%$ Liners Retaining BoltsA … Retaining Bolts-B l^^^^^pj ■Retaining Bolts-C Fig. 188.—Showing Points to Observe When Fitting Connecting Bod the case shown at C the light edges of the bushings arein contact, but the connecting rod and its cap do not meet.When the retaining nuts are tightened the entire strainis taken on the…
