MagnetoMagneto Drive Gear ^-Intake Gas Passage ..---- Carburetor ~~Primary /fir Intake. ~-EueI Pipe77/r Cooled Cylinder Fig. 195.—Sectional View Showing Internal Parts of Six-Cylinder AnzaniEngine, with Starwise Disposition of Cylinders. … rr 468 Aviation Engines be apparent that in the ten-cylinder form explosions willoccur every 72 degrees of crank-shaft rotation, while inthe twenty-cylinder, 200 horse-power engine at any in-
