Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 476
.---**-** Piston Rings -Cylinder ^ Valve Actuating Push Rod Fig. 201.—Sectional View of Early Type Gnome Cylinder and PistonShowing Construction and Application of Inlet and Exhaust Valves. The pistons, like the cylinders, are machined out ofthe solid bar of nickel steel, and have a portion of…
Airplanes
