Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 192
PLATE 58. Plate 59 shows the piston valve in the bushing, andcylinder.v Plate 60 shows a section through the saddle and cyl-inder. V represents the piston valve, C the cylinder, Ethe exhaust and S the steam passage. Plate 61 shows the piston valve bushing. The longi-tudinal strips or bridges are… … I k 182 VALVE MOTION.
Locomotives
