Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 493
i? Q> A i> -£ V Sc 5 ^ 5^ ^50 5 ct B -c: \ <0 tf\ ^ -yQ if. * Q_s * QvJgs … •a w ■s I a 2 q II o ■8 CO faO •iH Le Rhone Rotary Motor 495 are carried in the piston top instead of one. The valveoperating arrangement is different also, as a single fourpoint cam is nsed to operate the seven exhaust valves.It is driven by epicyclic gearing, the cam being driven byan internal…
Airplanes
