Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 239

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 239
200 DIRECT-CURRENT DYNAMOS TABLE XXRelation of Capacity and Type to Number of Poles Type Output in Kilowatts Number of Poles Direct-Connected 1 to 2,030 4 15 to 400 6 90 to 400 8 200 to 900 10 300 to 1,800 12 600 to 2,200 14 800 to 2,500 16 Low-Speed, Belted 1 to 600 4 15 to 600 6 High-Speed,…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
