Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 75
wall surfaces at the moment of explosion,when it is desirable that the greatest amount of heat isgenerated, and carrying with it the greatest possible press-ure from which the expansion takes place by the movementof the piston. The spherical form cannot continue during the strokefor mechanical… … Fig. 18.—Spherical CombustionChamber. Fig. 19.—Enlarged CombustionChamber. the combustion and expansion part of the stroke. Thisidea is illustrated in Figs. 18 and 19, showing how therelative volumes of cylinder stroke and combustion cham-ber may be varied to suit the requirements due to thequality…
