Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 91
gines Here we have one explosion during the first half of thefirst revolution in one cylinder and another during the firsthalf of the second revolution in the other cylinder. Witha four-cylinder engine there is an explosion each half revo-lution, while in a six-cylinder engine there is one and… … Note.-Read Figs. 3&4from Centers outward Is+S+r 2nd S+r 3rd 5+r 4th St 1st Revolution ONE CYCLE720<-0° 2nd Revolution
Airplanes
