shaft. The seat-board may be of pine, butpreferably is of tougher wood, such as oak or ash.Cut the board to the shape shown by Fig. 174, andfix with s-crews on the under-side from front to back ;a fillet of wood 2 in. w-ide by \ in. thick supports thecircular end, which is unsupported by the… … Fig. 175.—End of Mail-cart Well. quite through, and fix the board to the bambooshafts. Before fixing the seat-board to the shafts,the balusters forming the body are fixed in theirplaces. These, as will be seen, are not of equallengths ; the height at the centre of back is 10^ in.,while at the rear…
