Hetzel, Frederic Valerius, 1870- · New York, J. Wiley and Sons · leaf 175
t24-inch Head Pulley of BeltConveyor at Various Speeds. 144.—140 feet per minute.145.—275 feet per minute.146.—360 feet per minute.147.—780 feet per minute. 158 DISCHARGING FROM THE BELT The fine stuff which clings to the belt or which is brushed off in the tripperfalls over the end pulley, and if… … FIG. 148.—Path of Discharge over a Belt Pulley.TABLE 31.—VERTICAL ORDINATES, INCHES, FOR USE WITH FIG. 148 A .43 D 7.72 G 23.64 J 48.24 B 1.93 E 12.06 H SO. 87 K 58.37 C 4.34 F 17.37 I 39.07 L 69.47 Plows or Scrapers.—When belts handle material like wood chips, finecoal, dry chemicals, etc., which…
Conveying machinery · Hoisting machinery · Belts and belting
