Bench work in wood; a course of study and practice designed for the use of schools and colleges (1888)
Goss, William Freeman Myrick, 1878- · Boston : Ginn · leaf 93
By use of the gauge, lay off the lines fh, eg, etc., Face D,Fig. 137- OPERATIONS TO BE PERFORMED ON FACE C, FROM B AS AWORKING-FACE, FIG. 137. 131. The lines on this face are to be used in Exercise No. 3.By applying the principles already developed (121, 122) locatethe lines as shown by the… … BENCH WORK. 8l EXERCISE No. 2.PRACTICE WITH CHISEL AND GOUGE (39, 40, and 42). The stock required is | X 4? X 8- Fig. 145 shows the lines that are needed, all of which areproduced as explained in the foregoing exercise, except thearcs of circles, which must be put in with the dividers (26);A and B…
Woodwork (Manual training)
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
