rge amount of material near these surfaces. A rail-road rail or an I-beam are simple illustrations; a bridge truss is an elabo-ration of this principle. WOOD CONSTRUCTION, 133 Joints connecting Timbers in the Direction of their Length. 200. A Lapped Joint, shown by Fig. 229, fastened either… … Fish-pieces may be of either wood or iron, and may beemployed to form the fished joint shown in Fig. 230, or appliedto more comphcated joints to increase their strength. When subject to compressional strain, a fished joint shouldhave four plates, one on each face. When subject to tensionalstrain,…
