Bench work in wood: a course of study and practice designed for the use of schools and colleges (1902)
Goss, W. F. M. (William Freeman Myrick), 1859-1928 · Boston, Ginn & company · leaf 90
sition should be reversed as indi-cated by the dotted outline. This method must be observedin using any similar tool, as the try-square, bevel, etc. 123. Chalk-Lining (36). — Lay off points on lines ab andad y^ apart, the first point in each case being ^^ from theworking-face. Through the points… … beginning at the awl. Care must be taken that the cake ofchalk is not cut to pieces by the cord. A little practice willmake it easy to hold the cord under the thumb in such a wayas to form a small shoulder on the chalk, Fig. 139, which by 7^ BENCH WORK IN WOOD. the friction of the cord will be…
Woodwork (Manual training)
