versatec :: 5990-01 C2700 Series Thermal Transfer Color Plotter Operator Guide Oct1986 (1919)
leaf 47
sette cover (Figure 3-8). Note: Do not put more than 150 sheets (approximately 0.44in/11.2 mm thick) of paper in the media cassette at one time. Aline indicating the maximum allowable paper level is locatedinside the cassette (Figure 3-8). If you need to exchange media (from paper to film or vice… … MEDIA CASSETTE CASSETTE COVER Figure 3-8. Media Cassette C2700 SERIES THERMAL PLOTTER OPERATOR GUIDE 3-7 LOADING THE INK DONOR ROLL AND MEDIA Note: If you are using paper, either side is suitable for plotting. 4. Install the paper in the media cassette. Make sure the mediaretainers are both sitting…
