An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 156 — screw is not sufficient to hold the shank firmly in place. In Fig. 23 is shown a round shank, the shank having a flat top, with a set screw to hold the shank in position. A still better form of socket is shown in Fig. 24 the hole being circular and taper- Fig. 21. Details of Compass Joint ed. The…
